Cell Rubber Fender

Hilifting is the best marine rubber fender supplier in China, our cell fenders feature good performance at angular berthing and wider dispersion of stress, low tilt compression performance change and good resistance against the shear force that makes it be the first choice for many wharves.

Material: Natural Rubber

Diameter: 400mm to 3000mm

Type: Cell Fender or Supper Cell Fender

Features: Low tilt compression performance change and good resistance against shear force makes it the first choice for many wharfs

Category:
Share On

Cell Rubber Fender Specification:

Cell Rubber Fender Sketch

Product name Cell Rubber Fender
Material Natural Rubber
Size From 400mm to 3000mm
Applications Fast ferries and catamaran berths
Conventional Rope berths
Oil, liquid and bulk terminals
Multi-user facilities
Monopile and elastic dolphin structures
Open pile jetties and wharves
Locations with a very large tidal range
Lead-in structures and turning

Cell Rubber Fender Parameter Table:

Type(mm) H ΦDl ΦD2 h holes n- Φd
SC400H 400 550 650 25 4 30
SC500H 500 550 650 25 4 32
SC800H 800 900 1050 30 6 40
SC1000H 1000 1100 1300 35 6 47
SC1150H 1150 1300 1500 37 6 50
SC1250H 1250 1450 1650 40 6 53
SC1450H 1450 1650 1850 42 6 61
SC1600H 1600 1800 2000 50 8 61
SC1700H 1700 1900 2100 50 8 66
SC2000H 2000 2000 2200 50 8 74
SC2250H 2250 2300 2550 57 10 74
SC2500H 2500 2700 2950 70 10 90
SC3000H 3000 3150 3350 75 12 90

Shipping and Payment Term:

  • We generally ship cargos worldwide by sea. The goods will be in a shipping container when arriving at the port. You are responsible for picking up your shipment and customs clearance on your side.
  • We do accept small, urgent orders that need to be shipped by air.
  • We currently accept T/T & L/C.
  • Please contact us if you have any questions about shipping or payment, we will be happy to assist you.
